URF1D_HB-150WR3

Features

URF1D_HB-150WHR3 series is a high-performance product specifically designed for a variety of railway applications. The DC-DC converters feature up to 150W output power with no requirement for minimum load, ultra-wide input voltage from 43-160VDC. The products also provide input under-voltage protection, output over-voltage, short-circuit and over-temperature protection. Additional functions include remote On/Off control, remote sense compensation and output voltage trim adjustment. they are widely used in railway systems and associated equipment.

URF1D_HB-150WR3
MORE
Loading...

Swipe to view all →
Produkte No. Power(W) Vin(VDC) Vout(VDC) No. of Outputs Isolation(VDC) Package Dimension(mm) 3D Impression Drawing (.stp) Certification Datasheet Sample Buy
URF1D05HB-150WR3 150 43~160 5 1 3000VAC DIP 61*57.9*13.8 - CE - URF1D05HB-150WR3 - sample request buy on line
URF1D12HB-150WR3 150 43~160 12 1 3000VAC DIP 61*57.9*13.8 - CE - URF1D12HB-150WR3 - sample request buy on line
URF1D15HB-150WR3 150 43~160 15 1 3000VAC DIP 61*57.9*13.8 - CE - URF1D15HB-150WR3 - sample request buy on line
URF1D24HB-150WR3 150 43~160 24 1 3000VAC DIP 61*57.9*13.8 - CE - URF1D24HB-150WR3 - sample request buy on line
URF1D48HB-150WR3 150 43~160 48 1 3000VAC DIP 61*57.9*13.8 - CE - URF1D48HB-150WR3 - sample request buy on line

* Referenzparameter. Technsiche Details entnehmen Sie bitte dem zugehörigen Datenblatt

Produkte No.
URF1D05HB-150WR3
URF1D12HB-150WR3
URF1D15HB-150WR3
URF1D24HB-150WR3
URF1D48HB-150WR3
